    ISI222 Bachmann ISI222 Function Modules Positioning Modules Bachmann ISI222

    Ask Lasest Price
    Brand Name : BACHMANN
    Model Number : ISI222
    Certification : CO.CQ
    Price : inquiry
    Payment Terms : T/T
    Supply Ability : 10 pieces a day
    Delivery Time : today
    • Product Details
    • Company Profile

    ISI222 Bachmann ISI222 Function Modules Positioning Modules Bachmann ISI222

    ISI222 Bachmann ISI222 Function Modules Positioning Modules Bachmann ISI222


    Bachmann ISI222

    Function Modules


    ISI222

    Postioning Modules

    Especially designed for sophisticated motion controlapplications the IS1222 module offers compactequipment and optimum precision. Equipped forthe total control of two motion axes, the modulefeatures a number of encoder interfaces for positionacquisition, analog outputs for the application ofmanipulated variables, as well as digital inputs for thenitiator or trigger. Furthermore, due to the centralcommunication concept, all I/Os of the remainingMi system can also be incorporated into the motioncontrol (limit switches, etc).Input frequencies up to 8 MHZ and the integratedsynchronization (o-bus-sync)with the total systemallow highly dynamic and precise movements.
    Beside the full compatibility to the well provencontroller modules m-smc, m-cnc and m-shaft, alsothe user own programs and individually designedcontrol tasks can utilize the extensive integratedunctions of the module simply via the knownstandard interfaces (SVI, MIO). The extensiventegrated error monitoring with ongoing checking ofthe encoder resolution identifies hard-to-see wiringor ESD problems and allows the application especiallyunder diffcult environmental conditions
    • 2 input channels for incremental and Sslencoders
    • full 32 bit counter
    • 2 analog outputs (14 bit)
    • 4 fast digital input channels for initiator and trigger
    • Position measurement/position storage can beinitiated via triggers
    • Virtual for use in applications: zero pulse, speed,etc
    • Synchronization via SYNC/PRESYNC
    • Encoder supply via module
    • Monitoring of the encoder voltage
    • Wire break monitoring (encoder)
