MVI56-MCM Prosoft Modbus Master/Slave Enhanced Network Interface Module for ControlLogix

MVI56-MCM

The MVI56E Communication Module allows for Modbus Master and/or Slave connectivity from Rockwell Automation® ControlLogix® processors to Modbus RTU/ASCII devices. Each MVI56E port can be configured as a Master or Slave.

The MVI56E-MCM and MVI56E-MCMXT act as input/output modules on the ControlLogix backplane, making Modbus data appear as I/O data to the processor. Two independently configurable serial ports can operate on the same or different Modbus networks. The MVI56E-MCM is designed for standard process applications and the MVI56E-MCMXT is designed for the Logix-XT™ control platform, allowing it to operate in extreme environments. It can tolerate higher operating temperatures, and has conformal coating to protect it from harsh or caustic conditions.

Features and Benefits

Functional Specifications

The MVI56E-MCM will operate on a Local or Remote rack (For remote rack applications with smaller data packet size please refer to the MVI56E-MCMR product)

• Supports Enron version of Modbus protocol for floating-point data transactions
• PCB includes powerful Modbus network analyzer
• Special functions (command control, event commands, status, and so on) aresupported by message transfer (unscheduled) using the MSG instruction
• Error codes, network error counters, and port status data available in user data memory
