Allen Bradley Modules 440R-G23029 440R G23029 AB 440RG23029
GUARDMASTER MINTAUR SER
Product Description:
The name of the tag will reflect the name you assigned the earlier.
The "C" sub-group contains the contents of the configuration
assembly, which is not currently used in the 1203-CN1. The "O"
subgroup contains one entry for each word of output data you
configured, and the "I" sub-group contains one entry for each word
of input data you configured. The "O" sub-group corresponds
directly to output data for a PLC-5 described on page 5-2 of the
1203-CN1 user manual (i.e., for most common configurations, word 0
is the logic command, word 1 is the speed reference, words 2 and 3
are the first pair of data links, etc.). The "I" sub-group is
similar to the input data for a PLC-5, except that it is shifted by
two words (i.e., word 2 is the logic status, word 3 is the speed
feedback, etc.). Words 0 and 1 of the "I" sub-group represent
network status data sent by the 1203-CN1 but not processed directly
by the ControlLogix processor. At this point, I/O between the
ControlLogix processor and the 1203-CN1 should be configured and
running, and the meaning of the various I/O words should be
understood. If you need further assistance in configuring I/O,
please contact technical support.
